机械规格表
|
项 目 |
单 位 |
VBT-130 |
VBT-130A |
VBT-130B |
|
镗杆直径 |
mm |
130 |
130 |
130 |
|
W轴行程 |
mm |
700 |
700 |
700 |
|
X轴行程 |
mm |
2,500/3,000 3,500 |
3,000/3,500 4,500/5,500 |
4,500/5,500 6,500 |
|
Y轴行程 |
mm |
2,000/2,600 |
2,600/3,200 |
3,200/3,500 |
|
Z轴行程 |
mm |
1,500/2,000 |
1,500/2,000 |
2,000/2,500 |
|
主轴功率 |
mm |
22/30/37/45(选购) |
||
|
主轴转速 |
rpm |
35～3,500 |
||
|
工作台尺寸 |
mm |
1,400*1,600 1,600*1,800 |
1,800*2,200 2,500*2,500 |
2,500*2,500 2,500*3,000 |
|
工作台载重 |
kgs |
8,000/10,000/ 12,000 |
15,000/20,000 |
20,000/25,000/ 30,000/35,000 |
