| Project | unit | specification |
| X axis travel | mm | 500 |
| Y axis travel | mm | 400 |
| Z axis travel | mm | 350 |
| Table area | mm | 600x400 |
| Spindle speed | rpm | 10,000 |
| Spindle motor specifications | KW | 3.7/2.2 |
| Three axis displacement rate | m/min | 36/36/48 |
| Taper of spindle specification | BT-30 |
