| Project | unit | A5630 | A5640 | A7030 | A7040 |
| X axis travel | mm | 560 | 560 | 700 | 700 |
| Y axis travel | mm | 400 | 400 | 400 | 400 |
| Z axis travel | mm | 350 | 550 | 350 | 550 |
| Table area | mm | 650X430 | 650X430 | 800X430 | 800X430 |
| Spindle speed | rpm | 8,000~24,000 | 8,000~15,000 | 8,000~24,000 | 8,000~15,000 |
| Spindle motor specification | KW | 5.5 | 7.5 | 5.5 | 7.5 |
| Three axis displacement rate | m/min | 48/48/60 | 48/48/48 | 48/48/48 | 48/48/48 |
| Taper of spindle specification | BT-30 | BT-40 | BT-30 | BT-40 |
