| Item | Unit | NF-xx23 series | NF-xx26 series |
| X axis travel | mm | 2,200~10,200 | 3,200~10,200 |
| Y axis travel | mm | 2,300/3,000 | 2,600/3,300 |
| Z axis travel (track) | mm | 920 / 1,020 | |
| Z axis travel (rail) | mm | 1,000 / 1,200 | |
| Spindle speed | rpm | 4,500/6,000/ 8,000/10,000 | |
| Spindle motor specifications | KW | 18.5/22 (22/26 optional) | |
| Cutting feed rate | mm/min | 1-7,000 | |
| Table maximum load | kg | 9,000~26,000 | 13,000~26,000 |
