| Project | unit | VP2012 | VP3012 | VP4012 | VP5012 |
| X axis travel | mm | 2,000 | 3,000 | 4,000 | 5,000 |
| Y axis travel | mm | 1,200 | |||
| Z axis travel | mm | 760 | |||
| The distance between the posts | mm | 1,300 | |||
| Table size (X * Y) | mm | 2,000X1,100 | 3,000X1,100 | 4,000X1,100 | 5,000X1,100 |
| Table maximum load weight | kg | 3,500 | 4,500 | 6,000 | 8,000 |
| Spindle speed | rpm | 6,000 (8,000/10,000 optional) | |||
| Spindle motor | KW | 15/18.5 | |||
| X/Y rapid feed | mm/min | 20,000 | |||
| Z rapid feed | mm/min | 15,000 | |||
